Equipment

We have a well equipped welding facility with the capability to weld aluminum, stainless steel, mild steel, magnesium etc. Additionally, we can cut metal using either flame or plasma cutting methods. Additional metal cutting capabilities consist of drilling, milling, turning, surface grinding, sawing and automated cutting.  Plastic thermoforming is also available.

Stay tuned as we are updating this page with our new equipment!

Drilling

Picture Brand Model Uses Job Specs & Materials Quantity Location
18 inches drill Powermatic PM2800B Drill Press
  • Milling
  • Drilling
  • Tapping
  • Boring
  • 24" x 14" x 16"
  • Metals
 1 Mini-Shop

Sawing

Picture Brand Model Uses Job Specs & Materials Quantity Location
Clausing Kalamazoo H9AW Horizontal Band Saw

Clausing Kalamazoo

H9AW Horizontal Bandsaw

Cutting large stock (>0.5") to length
  • Max stock, square: 8" x 13"
  • Max stock, round: 9"
  • Metals
  • Plastics
 1 Weld Shop
Picture Brand Model Uses Job Specs & Materials Quantity Location
Clausing Startrite 20V Vertical Band Saw

Clausing Startrite

20V Vertical Band Saw

Cutting large stock (>0.5") to length
  • Max cut length: 20"
  • Metals
  • Plastics

1

Weld Shop

Surface Grinding

Picture Brand Model Uses Job Specs & Materials Quantity Location
Clausing Equiptop 6" x 18" Precision Surface Grinder

Clausing Equiptop

6" x 18" Precision Surface Grinder

Precision finishing of surfaces by grinding -- make surfaces very flat, parallel or cylindrical.
  • Max Grinding Length: 19"
  • Max Grinding Width: 7"
  • Max Grinding Height: 18"

  • Metals (both annealed and hardened)

1

Weld Shop
Picture Brand Model Uses Job Specs & Materials Quantity Location
Wilton Belt/Disc Sander

Wilton

Belt / Disc Sander

Material removal, sharpening and deburring.
  • Plastics
  • Wood
  • Metals (including aluminum)

1

Mini Shop
Picture Brand Model Uses Job Specs & Materials Quantity Location
Baldor Bench Grinder with Floor Stand

Clausing Equiptop

6" x 18" Precision Surface Grinder

Metal removal, sharpening and deburring. Can be used to "grind" hardened steels that cannot be cut using conventional cutting tools.
  • Ferrous metals only (steel, stainless steel, cast iron)

  • NO ALUMINUM

1

Mini Shop

3D Printing

Picture Brand Model Uses Job Specs & Materials Quantity Location
Prusa i3

Prusa

Mini

FDM (Fused Deposition Modeling) 3D printing
  • Build volume: 7" x 7" x 7"
  • PLA only

8

3D Print Farm
Prusa i3

Prusa

i3

FDM (Fused Deposition Modeling) 3D printing
  • Build volume: 9.84" x 8.3" x 8.3"
  • PLA
  • ABS
  • PET
  • HIPS
  • Flex PP
  • (more materials here)

16

3D Printing Lab
Ultimaker 3S

Ultimaker

3S

FDM (Fused Deposition Modeling) 3D printing
  • Build volume: 9" x 7.4" x 7.9"
  • PLA
  • ABS
  • Nylon
  • CPE/+
  • PC
  • PP
  • PVA
  • (more materials here)

2

3D Printing Lab
Picture Brand Model Uses Job Specs & Materials Quantity Location
Formlabs 3

Formlabs

3

SLA (Stereolithography) 3D printing
  • Build volume: 5.7" x 5.7" x 7.3"
  • Resin from Formlabs (see here)

1

3D Printing Lab
Picture Brand Model Uses Job Specs & Materials Quantity Location
EinScan-SE

Shining 3D

EinScan-SE

3D scanning
  • Min scan volume: 30 x 30 x 30 mm
  • Max scan volume (fixed scan): 700 x 700 x 700 mm
  • Max scan volume (auto scan): 200 x 200 x 200 mm

1

3D Printing Lab

Automated Cutting

Picture Brand Model Uses Job Specs & Materials Quantity Location
Omax 2652 Abrasive Waterjet Cutter

Omax

2652 Abrasive Waterjet Cutter

CNC cutting of planar entities
  • Work envelope: 24" x 24"
  • Machining tolerance: +/- 0.005"
  • Non-Brittle plastics
  • All Metals
  • Stone
  • Ceramic Tiles
  • Glass

1

Weld Shop



Picture Brand Model Uses Job Specs & Materials Quantity Location
Epilog Helix

Epilog

Helix

Cut and engrave on various materials
  • 24" x 18"
  • See all materials here

3

Laser Cutter Room
Trotech Speedy 300 Laser Engraver

Trotec

Speedy 300

Cut and engrave on various materials
  • 29" x 17"

Engrave only:

  • Textiles
  • Glass
  • Metal (list)

Engrave and cut:

  • Laminates
  • Leather
  • Acrylic
  • Paper
  • Plastics
  • Stone
  • Wood

1

Laser Cutter Room

Milling

Uses


Clausing Kondia FV60 Knee Mill with 2-axis CNC Accurite Controller

Milling, drilling, tapping, boring and 2axis CNC machining.

Materials

Plastics, Metals

Video Demonstrations

  • Manual Facing (4 MB MPEG 1.3 MB WMV)
  • CNC Circular Interp (2 MB MPEG .2 MB WMV)

Job Specifications

  • Work Envelope: 24" x 14" x 16"

Specifications

  • Dimensions: 78" L x 100 W" x 82.5" H
  • Weight: 3306 lb
  • X, Y Travel: 28", 14.375",
  • Z Travel: Quill, Knee: 5.0", 16.5"
  • Max Table Load: 1050 lbs
  • RPM Range 1: 60-4000
  • Spindle Taper: R8
  • Spindle Power: 3 Hp
  • Controller: Accurite 2-Axis (X,Y) CNC
  • X ,Y Rapid Rates: 100 in/min
  • Postioning Accuracy .0002"
  • DXF file format import
  • Conversational programming

Resources

Uses

TBA

Materials

Plastics and metals

Job Specifications

  • Work Envelope: 42" long x 9" wide x 12" tall

Specifications

Resources

Hurco VM10i

Torchmach 770M

Turning

Clausing Colchester 15" x 40" Geared Head Manual Lathes Turning simple cylindrical shapes including grooves, on-axis holes, straight threads, straight bores etc.

Materials

Plastics and metals

Video Demonstrations

  • OD Profiling (3.3 MB MPEG 1 MB WMV)

Job Specifications

  • Work Envelope: 15"diameter x 50" long"

Specifications

  • Dimensions: 99" L x 49" W x 51" H
  • Weight: 3300 lb
  • X travel: 9.8"
  • Z travel: 50"
  • RPM Range :25-2000
  • Swing over Cross Slide: 9.7 in
  • Tailstock Tape: 5MT
  • Spindle Taper: 5MT
  • Main Spindle Nose: D1-6
  • 8" 3 jaw chuck
  • Manual collet closer
  • Motor: 7.5 Hp

Resources

Uses

TBA

Materials

Plastics and metals

Job Specifications

  • Work Envelope: 6" diameter x 40" length

Specifications

Resources

Welding

Widget Title
Miller Millermatic 210 MIG Welder

Miller Millermatic 210 MIG Welder

Uses

Welding metals

Materials

Alloy and mild steels

Resources

Widget Title
Miller 180SD TIG Welder

Miller 180SD TIG Welder

Uses

TIG (Tungsten Inert Gas) and SMAW (Shielded Metal Arc Welding)

Materials

  • Steel
  • Stainless
  • Titanium
  • Aluminum

Job Specifications

  • Work Envelope: 24" x 24"

Device Specifications

  • Rated Output at 40% Duty Cycle: 150 A
  • Welding Amperage Range: 10A-180A
  • Max Open-Circuit Voltage: 80V
  • Dimensions: 22.1" L x 13.6" W x 21" H
  • Weigth: 210 lbs

Resources

Widget Title
Hypertherm Powermax 600 Plasma Cutter

Hypertherm Powermax 600 Plasma Cutter

Uses

Cutting of metals

Materials

  • Aluminum
  • Mild steel
  • Stainless Steel

Device Specifications

  • Rated Output: 20A-40A
  • Rated Output at 50% Duty Cycle: 40 A, 140V
  • Rated Open-Circuit Voltage: 300V
  • Dimensions: 22.1" L x 13.6" W x 21" H
  • Max Cutting Capacity: 5/8" @ 50% Duty Cycle
  • Gas Type: Air or Nitrogen



Resources

Widget Title
Oxy-Acetylene Gas Welding/Cutting Outfit

Oxy-Acetylene Gas Welding/Cutting Outfit

Uses

Welding, brazing and flame cutting of metals.

Materials

  • Welding and cutting of mild steels
  • Brazing of many metals such as copper, SS, brass, chromoly etc.
Widget Title
Miller Spot Welder

Miller SS-1020 ATT Spot Welder

Uses

Resistance welding of sheet metal.

Materials

  • Aluminum
  • Steel
  • Stainless steel.

Job Specifications

  • Max spot weld reach: 12"
  • Max thickness (mild steel): 3/16 in

Device Specifications

  • Dimensions: 21.75" L x 11" W x 49" H
  • Weight: 170 lbs
  • Rated Output (12" tongs):
  • Built-in Spot Timer
  • Air actuated tongs

Resources

Widget Title
Miller Electric Resistance Spot Welder

Miller Electric Resistance Spot Welder

Thermal Arc Prowave 185 TSW Welder

Miller MIG 350P Wirefeed

Sheet Metal

Widget Title
24" Sheet Metal Shear

24" sheet metal shear

Widget Title
24" Sheet Metal Brake

24" sheet metal brake

Uses

Shearing metal and plastic sheet.

Materials

Steel, aluminum, plastic

Capacity

  • 48" wide sheet.
  • Mild Steel .060" thick
  • Aluminum .100" thick
  • Stainless Steel .031" thick
  • Plastic .200" thick

Device Specifications

  • Model: FK-H4816
  • Weight: 988 lbs
Widget Title
48" Sheet Metal Brake

Uses

Bending sheet metal and plastics.

Materials

Metal and plastic sheet such as mild steel, stainless steel aluminum and ABS. Thickness depends on material.

Capacity

  • 48" sheet, thickness depends on material
  • Bends up to 100 degrees
  • Mild Steel .040 thick
  • Aluminum .060 thick
  • Stainless Steel .031 thick
Widget Title
90° Sheet Metal Notcher

Uses

Cutting 90 degree notches in metal and plastic sheet.

Materials

Metal and plastic sheet.

Capacity

  • Mild Steel .060" thick
  • Aluminum .100" thick
  • Stainless Steel .031" thick
  • Plastic .200" thick
Widget Title
Sheet Metal Punch Press

Materials

Metals

Description

Thermo-Forming

Formech Model 660 Vaccuum Thermoforming Machine

Uses

Forming plastic sheet by heating and then applying vacuum through a mold cavity or core.

Materials

ABS, PETG

Job Specifications

  • Max Mold Size: 24" x 24"
  • Max Depth of Draw: 26"
  • Max Material Thickness: .125"

Device Specifications

  • Dimensions: 71.6" L x 27.5" W x 47.2" H
  • Weight: 484 lb

Resources

Morgan Industries Plastic Injection Molding Machine 4 oz. G-100T
